Two-Position Six-Way Solenoid Valve

hydraulic solenoid valve Structure and flow path diagram

Two-position six-way directional control valve, also known as two-position six-way control valve, its main structure is composed of import and export interface, valve body, valve core, control lever and other parts, wherein the valve body is provided with a corresponding flow channel, used to control the direction of fluid in and out.The flow path diagram is shown below：

Among them, A, B, P, and C are the inlet, outlet, internal connection port, and control port respectively.Among them, ports A and B can be connected to different hydraulic sources and actuators, and ports P and C are the directions of the valve core control, which can realize hydraulic control in different directions.

Work process

When the valve core is in the initial position, the fluid enters the valve body from port A, and the flow channel controlled by the valve core enters port P. At the same time, the fluid between port C and port B is closed, realizing the control of the flow of port A into port P.When the valve core moves to the termination position, the fluid enters the valve body from port A, and enters port B through another flow channel controlled by the valve core. At the same time, the fluid between port C and port P can be unobstructed, realizing the control of the flow of port A into port B.

Features and precautions

The two-position six-way directional control valve has the advantages of easy control, simple structure, and relatively cheap price.But in practical applications, we need to pay attention to the following points：

1. Valve specifications and models should be selected according to specific hydraulic system conditions and control requirements；

2. During installation and use, attention should be paid to the sealing performance and pressure resistance of the valve；

3. Adding too many two-position six-way directional control valves to the oil pipeline may cause the complexity of the system to increase and the difficulty of maintenance to increase.

Two-position six-way directional control valve is a common hydraulic control valve with a wide range of applications, but it needs to be reasonably selected and used correctly according to specific circumstances in use.
